Caracteristici generale
Numar Porturi
48x RJ45
4x SFP (uplink)
Viteza Transfer LAN
10/100/1000 Mbps
Tehnologie de cablare
RJ45 Base-T
Standarde
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at
Securitate
Secure Shell (SSH), RADIUS, TACACS+
Caracteristici speciale
ARP support, trunking, VLAN support, IGMP snooping, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Port Aggregation Protocol (PAgP) support, Access Control List (ACL) support, Quality of Service (QoS), RADIUS support, MLD snooping, Dynamic ARP Inspection (DAI), EIGRP Stub Routing, Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Link Aggregation Control Protocol (LACP), Remote Switch Port Analyzer (RSPAN), Energy Efficient Ethernet, Flexible NetFlow (FNF)
Metoda forwarding
77.37 Mpps
Protocoale de rutare
RIP-1, RIP-2, EIGRP, static IP routing, RIPng
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, SSH, CLI
LED Indicators
Port transmission speed, port duplex mode, system, active, status, PoE
Tensiune de intrare
AC 120/230 V (50/60 Hz)
Alimentare
Sursa interna 1025W
Dimensiuni
445 x 44 x 486 mm
