Caracteristici generale
Viteza Transfer LAN
10/100/1000 Mbps
Tehnologie de cablare
RJ45 Base-T
Standarde
IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at
Rutare IP
IPv4: 64000
IPv6: 32000
Caracteristici speciale
Trunking, full duplex mode, Non-Stop Forwarding (NSF), Weighted Random Early Detection (WRED), Spanning Tree Protocol (STP) support, Access Control List (ACL) support, Quality of Service (QoS), Remote Switch Port Analyzer (RSPAN), Management Information Base (MIB), Virtual Routing and Forwarding (VRF), Cisco StackWise-480 technology, Cisco StackPower technology, Flexible NetFlow (FNF), 802.1x authentication, FTP client, Precision Time Protocol (PTP), MACsec support, 3 fans, VXLAN tunnel endpoints (VTEP) support, Control plane protection (CoPP), Location ID Separation Protocol (LISP), Source-Specific Multicast (SSM), integrated Wireshark, VLAN Double Tagging (Q-in-Q), Private VLAN, CoAP support, Security Group Tag (SGT) caching, Audio Video Bridging (AVB), Graceful Insertion and Removal (GIR) mode
Metoda forwarding
190.48 Mpps
547.62 Mpps (cu stacking)
Switch capacity
256 Gbps
736 Gbps (cu stacking)
Protocoale de rutare
OSPF, IS-IS, RIP-1, RIP-2, BGP, EIGRP, HSRP, IGMP, VRRP, PIM-SM, OSPFv3, PIM-SSM, Bidirectional PIM, MSDP, policy-based routing (PBR), RIPng, MPLS
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF
Tensiune de intrare
120/230 V (50 - 60 Hz)
Alimentare
Sursa interna 1100W
Dimensiuni
445 x 44 x 488 mm
Altele
Pentru functionare necesita Licenta DNA Advantage
