Caracteristici generale
Viteza Transfer LAN
10/100/1000/2500/5000/10000 Mbps
Tehnologie de cablare
RJ45 Base-T
Standarde
IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at
Rutare IP
IPv4: 64000
IPv6: 32000
Caracteristici speciale
Trunking, full duplex mode, Weighted Random Early Detection (WRED), Spanning Tree Protocol (STP) support, Access Control List (ACL) support, Quality of Service (QoS), Remote Switch Port Analyzer (RSPAN), Management Information Base (MIB), Cisco StackWise-480 technology, Cisco StackPower technology, Flexible NetFlow (FNF), 802.1x authentication, FTP client, 3 fans, Control plane protection (CoPP), 64MB packet buffer, Source-Specific Multicast (SSM), integrated Wireshark, VLAN Double Tagging (Q-in-Q), Private VLAN
Metoda forwarding
476.19 Mpps
833.33 Mpps (cu stacking)
Switch capacity
640 Gbps
1.12 Tbps (cu stacking)
Protocoale de rutare
OSPF, IS-IS, RIP-1, RIP-2, IGMP, VRRP, PIM-SM, OSPFv3, PIM-SSM, policy-based routing (PBR), RIPng
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF
Tensiune de intrare
AC 100-240 V (50/60 Hz)
Alimentare
Sursa interna 1100W
Dimensiuni
445 x 44 x 470 mm
Altele
Pentru functionare necesita Licenta DNA Advantage
